31" x 80" KENT USA HR-30 SERIES MANUAL PRECISION LATHE - NEW

Type

Lathes, Toolroom

Manufacturer

KENT

Model

HR-30

Year

Not provided

Stock #

12786

Condition

New

Request A Quote

Keep Scrolling To Learn More

31" x 80" KENT USA HR-30 SERIES MANUAL PRECISION LATHE - NEW

Specifications

Equipped With

31" x 80" KENT USA HR-30 SERIES MANUAL PRECISION LATHE - NEW

PRODUCT HIGHLIGHTS

20 HP Spindle Motor, 12-Speeds
4.1” (6.1” Opt)Spindle Through Hole
Solid One Piece Full Length Casting Base and Bedways for Maximum Rigidity
Spindle Jog Button Control
One-shot Lubrication for Apron, Multi-position Adjustable Feed Position Stops
Dual Inch/Metric Calibrated Tailstock Quill with Knockout Tang; Heavy Duty Two Speed Tailstock
Dual Inch/Metric Dials (Optional)

STANDARD ACCESSORIES

Halogen work light
3-position carriage stop
4-position tool post
Thread chasing dial
Steady rest
Coolant system

OPTIONAL ACCESSORIES

Digital Readout System
Royal spindle type live center
Taper turning attachment
BTC 3-jaw chuck with back plate
Micrometer carriage stop
Rustlick coolant

Swing Over Bed
Swing Over Cross Slide
Swing Over Gap
Width of Bed
Distance Between Centers
Cross Slide Travel
Top Slide Travel
Spindle Speeds
Spindle Speed Range
Through Hole Diameter
Spindle Nose
Spindle Bore Taper
Thread – Standard (Whit-worth)
Thread – Metric Pitch
Longitudinal Feed
Cross Feed
Lead Screw Diameter
Threading Pitch
Quill Travel
Quill Diameter
Quill Bore Taper
Main Motor
Coolant Pump Motor
Machine Dimension
Packing Dimension
Machine weight
Packing weight

HR-30 Series
30.7"
21.25"
42.1"
18"
80" (Opt 120" / 160")
15.35"
9.4"
12
14-1000 RPM
4.1" (Opt 6.1")
D1-11 or A1-11
MT#7 - MT#5
36 (2-72) TPI
65 (0.8-14) mm
0.002" - 0.0276" IPM
.001 - .00138"
NA
NA
8.3"
4.133"
MT#6
20 HP
1/8 HP
NA
151" / 198" / 232" / 270" x 69" x 73"
NA
NA
